ChamSys QuickQ 30 Lighting Control Console
Details
Details
The ChamSys QuickQ 30 is an intuitive lighting control console designed for dimmer, LED color mixing, and moving light fixtures. Featuring a 9.7-inch multi-touch display, it simplifies setup, programming, and playback.
With built-in Wi-Fi for remote app connectivity and support for RDM compliant fixtures, the QuickQ 30 is ideal for novice users and offers extensive programming capabilities.
| Specification | Details |
|---|---|
| Universes Supported | 4 |
| Direct DMX Outputs | 3 (5-Pin XLR) |
| Master Playback Faders | 10 |
| Multi-Function Fixture Faders | 40 |
| Bump Buttons | Yes |
| Attribute Encoders | 4 |
| Dedicated Hue/Saturation Encoders | Yes |
| Inbuilt Display | 9.7” Multi-touch |
| External Monitor Support | 1920 x 1080 HDMI |
| Inbuilt Wi-Fi | Yes |
| Network Port | 1 |
| USB Ports | 2 |
| Audio Input | 1 |
| Audio Output | 1 |
| MIDI Ports | In/Out |
| Max Power Consumption | 60W |
| Max DMX Channels | 2048 |
| Max Fixtures Supported | 2048 |
| Max Cue Stacks | 10 |
| Max Chases | 10 |
| MIDI & Timecode Support | Yes |
| RDM Autopatch | Yes |
| Fixture Library | Over 30,000 personalities |
| Offline Designer Software | Available for Windows and Mac |
