NEXO GEO M1210-I Loudspeaker
The GEO M1210-I is 2-way passive or active line array element with 12″ LF and 3″ voice coil / 1.4″ throat HF drivers. Measuring 700mm wide x 370mm high x 446mm deep and weighing 34kg, the
GEO M1210-I is an installation version of the GEOM12 with 10° vertical dispersion. Cabinets can be set for 80° or 120° horizontal dispersion using magnetic flanges in the waveguide, with no tools required. Cabinets are constructed from a honeycomb-structure urethane co-polymer material and feature integral rigging with no loose parts and handles on the rear and sides. GEO M1210-I is available in black, white or custom RAL colours.
Key Features- Powerful line array element that can be stacked or flown, with or without its companion sub the MSUB18
- Integrated rigging hardware with no loose part and AutoRigTM feature
- Incorporates latest NEXO patented technology from the flagship STM series
- Comprehensive range of versatile, multifunction accessories for deploying the GEO M12 in a wide variety of applications
- Available in black, white and custom RAL colours
Specifications- Frequency Response @-6 dB - 50 Hz to 20 kHz
- Sensitivity 1W@1m - 105 dB SPL Nominal
- Peak SPL@1m - 140 dB
- Vertical Dispersion - 10°
- Horizontal Dispersion - 80° / 120°
- Passive Mode Crossover Frequency - 1.1 kHz
- Nominal Impedance - Active mode: (8 Ω LF + 16 Ω HF) / Passive mode: 8 Ω
- Recommended Power - Active mode: (1250 Watts LF + 625 W HF) / Passive mode: 1250 Watts
Features- LF Component - 1 x 12” 8 Ohms long excursion Neodymium driver with PDDTM
- HF Component - 1 x 3” voice coil 1.4” throat driver on a BEA/FEA optimised HR WavesourceTM
- Height x Width x Depth - 370mm x 700mm x 446 mm (14.6” x 27.6” x17.6”)
- Weight: Net - 34 kg (75 lbs)
- Connectors - 2 x Cable gland with 4 cores cables
- Active / Passive mode selection - Ruggedised, recessed, waterproof 2 position switch
- Construction - Lightweight Polyurethane Composite
- Fittings - 2 x Side handles horizontal + back grip
- Front Finish - Acoustic fabric fitted front grill
- Operating temperature range - 0°C - 40 °C (32° F - 104° F)
- Storage temperature range - -20 °C - 60 °C (-4 ° F - 140° F)
System Operation Recommended powering solution – NXAMP4x4 Powered TDcontroller: 3 x GEO M12 per channel Optional powering solution – NXAMP4x2mk2 Powered TDcontroller: 1 x GEO M12 per channel Optional powering solution – NXAMP4x1mk2 Powered TDcontroller (Bridged): up to 2 x GEOM12 per channel ]
